Klinogicare® Shockwave Storm Radial
Professional Radial Shockwave Therapy Device
- Adjustable pressure up to 7 bar and frequency range 1-21 Hz for precise treatment customization
- Extensive range of applicators designed to match specific anatomical zones and therapeutic goals - allowing the device to adapt to the clinician’s technique
- Contact radial shockwave technology ensuring accurate energy delivery and maximum control during treatment
Technology Background and Clinical Context
Radial shockwave therapy is primarily used for the treatment of superficial soft-tissue conditions, myofascial pain syndromes, and overload-related musculoskeletal disorders. Its clinical effectiveness has been well documented in the management of plantar fasciitis, tendinopathies, muscle injuries, and trigger points. At the same time, radial shockwave technology is not intended for deep tissue penetration or intra-articular pathologies.
Key technical consideration. Even at energy levels of 200 mJ, radial shockwave therapy remains a surface-oriented modality.
Radial shockwaves:
The fundamental physics of radial shockwave generation has remained essentially unchanged for over 20 years:
Practical differentiation between systems. As a result, the key differences between radial shockwave systems lie not in advertised pressure or energy values, but in:
Key technical consideration. Even at energy levels of 200 mJ, radial shockwave therapy remains a surface-oriented modality.
Radial shockwaves:
- disperse outward from the applicator,
- have no focal point,
- progressively lose energy with depth,
- and are clinically effective primarily within a 2–4 cm penetration range.
The fundamental physics of radial shockwave generation has remained essentially unchanged for over 20 years:
- pneumatic or electromagnetic energy generation,
- mechanical impact on the applicator,
- propagation of a dispersed radial wave.
Practical differentiation between systems. As a result, the key differences between radial shockwave systems lie not in advertised pressure or energy values, but in:
- pulse stability,
- durability of the impact mechanism,
- ease of use,
- and overall clinical versatility.
RSWT - Radial ShockWave Therapy. FSWT - Focused ShockWave Therapy.
Spatial-Average Temporal-Average Intensity:
Energy Flux Density:
Ultrasound consists of rapid oscillations (like sound waves) that act gently over a prolonged duration. This is why we measure the average power over a period of time. Ultrasound uses I-SATA because it is a continuous or pulsed "stream" of energy.
Shockwave (FSWT/RSWT) involves an instantaneous and powerful pulse. For this reason, it is more important to determine the energy density of that specific "impact" as it penetrates the tissues. Shockwaves use EFD because they are high-energy "events" or "shocks."
Spatial-Average Temporal-Average Intensity:
- Meaning: Ultrasound devices operate either continuously or in pulse mode. SATA represents the average ultrasound power, averaged over both the transducer's cross-sectional area and the total exposure time (including the "off" periods between pulses);
- Measurement Units: Watts per square centimeter (W/cm^2 or mW/cm^2).
- Purpose: This metric reflects the total thermal load on the tissues. It helps the clinician understand how much the target area will heat up during a prolonged treatment session.
Energy Flux Density:
- Meaning: Shockwave therapy is not just a vibration; it is a series of short, high-pressure "shocks" (pressure pulses). EFD indicates the amount of energy delivered to a single square millimeter of area at the focal point (the center) of the impact.
- Measurement Units: Millijoules per square millimeter (mJ/mm^2).,
- Low energy (<0.08\, mJ/mm^2): used for treating trigger points and tissue regeneration.
- Medium/High energy (>0.28\, mJ/mm^2): used for breaking down calcifications or treating bone-related issues.
Ultrasound consists of rapid oscillations (like sound waves) that act gently over a prolonged duration. This is why we measure the average power over a period of time. Ultrasound uses I-SATA because it is a continuous or pulsed "stream" of energy.
Shockwave (FSWT/RSWT) involves an instantaneous and powerful pulse. For this reason, it is more important to determine the energy density of that specific "impact" as it penetrates the tissues. Shockwaves use EFD because they are high-energy "events" or "shocks."
Technical and Clinical Considerations:
It is essential to clearly distinguish the capabilities and inherent limitations of radial shockwave therapy when evaluating its clinical applications.
An output level of 200 mJ in radial shockwave systems represents a relatively high value within this modality; however, it does not equate to the therapeutic characteristics of focused shockwave therapy. Radial shockwave therapy is primarily indicated for superficial soft-tissue conditions and myofascial disorders, whereas focused shockwave therapy is specifically designed to address deep tissue structures and intraosseous or orthopedic pathologies.
Physical Characteristics of Radial Shockwaves. Radial shockwaves are generated at the applicator tip and propagate into tissue as diverging pressure waves without a focal point. As a result, the energy density decreases rapidly with depth due to geometric dispersion and tissue attenuation. Even at higher nominal energy values (e.g., 200 mJ), the effective therapeutic depth of radial shockwaves is physiologically limited and typically does not exceed 2-4 cm, depending on tissue composition and treatment technique.
Limitations of Quantitative Output Parameters. Unlike focused shockwave systems, radial shockwave therapy lacks standardized, tissue-referenced metrics for energy delivery and clinical effectiveness:
Clinically Relevant Performance Parameters. Given these limitations, meaningful differentiation between radial shockwave systems should be based not on nominal output values but on operational and biomechanical performance characteristics that influence clinical outcomes.
Key parameters include:
Rather than emphasizing historical legacy or abstract performance claims, the presented systems are evaluated as practical clinical tools, designed to deliver repeatable and predictable therapeutic effects under routine clinical conditions.
An output level of 200 mJ in radial shockwave systems represents a relatively high value within this modality; however, it does not equate to the therapeutic characteristics of focused shockwave therapy. Radial shockwave therapy is primarily indicated for superficial soft-tissue conditions and myofascial disorders, whereas focused shockwave therapy is specifically designed to address deep tissue structures and intraosseous or orthopedic pathologies.
Physical Characteristics of Radial Shockwaves. Radial shockwaves are generated at the applicator tip and propagate into tissue as diverging pressure waves without a focal point. As a result, the energy density decreases rapidly with depth due to geometric dispersion and tissue attenuation. Even at higher nominal energy values (e.g., 200 mJ), the effective therapeutic depth of radial shockwaves is physiologically limited and typically does not exceed 2-4 cm, depending on tissue composition and treatment technique.
Limitations of Quantitative Output Parameters. Unlike focused shockwave systems, radial shockwave therapy lacks standardized, tissue-referenced metrics for energy delivery and clinical effectiveness:
- Bar values represent pneumatic system pressure and do not directly correspond to energy deposition in biological tissue
- mJ values describe mechanical impact energy at the applicator, without accounting for dispersion and tissue losses
- Hz reflects pulse repetition frequency rather than therapeutic efficacy
Clinically Relevant Performance Parameters. Given these limitations, meaningful differentiation between radial shockwave systems should be based not on nominal output values but on operational and biomechanical performance characteristics that influence clinical outcomes.
Key parameters include:
- Pulse-to-pulse energy stability across extended treatment sessions
- Durability of the impact generation mechanism and maintenance of output consistency over time
- Applicator geometry and diameter, influencing surface energy distribution and pressure gradients
- Energy coupling efficiency at the tissue interface and attenuation behavior within superficial layers
- Reproducibility of the effective penetration depth under clinical conditions
Rather than emphasizing historical legacy or abstract performance claims, the presented systems are evaluated as practical clinical tools, designed to deliver repeatable and predictable therapeutic effects under routine clinical conditions.
Description
Klinogicare® Shockwave Storm Radial is a portable radial shockwave therapy system designed for controlled stimulation of superficial soft tissues. The device delivers acoustic pressure waves with adjustable parameters, enabling consistent volumetric tissue interaction across a defined treatment area. Interchangeable applicators of different shapes and diameters allow adaptation to various anatomical regions and clinical indications.
Operating principle
The system generates radial shockwaves through an accelerated projectile mechanism inside the applicator. The resulting mechanical pressure wave propagates radially into the tissues, leading to mechanical stimulation that supports local microcirculation, modulates nociceptive signaling, and facilitates soft tissue recovery processes.
Treatment protocol
Clinical practice shows that measurable improvement is commonly observed after 3–4 treatment sessions performed at weekly intervals. A typical session duration is approximately 10 minutes, allowing standardized and time-efficient therapy delivery.
Clinical characteristics
Adjustable pressure and frequency parameters (0.5–7 bar, 1–21 Hz) enable controlled application for both acute and chronic soft tissue conditions. The system provides reproducible output, supporting predictable clinical responses when used with appropriate technique and parameter selection.
Patient tolerance
Radial shockwave therapy is non-invasive and generally well tolerated. Transient local reactions such as mild discomfort or erythema may occur, without functional limitations or recovery time.
Operating principle
The system generates radial shockwaves through an accelerated projectile mechanism inside the applicator. The resulting mechanical pressure wave propagates radially into the tissues, leading to mechanical stimulation that supports local microcirculation, modulates nociceptive signaling, and facilitates soft tissue recovery processes.
Treatment protocol
Clinical practice shows that measurable improvement is commonly observed after 3–4 treatment sessions performed at weekly intervals. A typical session duration is approximately 10 minutes, allowing standardized and time-efficient therapy delivery.
Clinical characteristics
Adjustable pressure and frequency parameters (0.5–7 bar, 1–21 Hz) enable controlled application for both acute and chronic soft tissue conditions. The system provides reproducible output, supporting predictable clinical responses when used with appropriate technique and parameter selection.
Patient tolerance
Radial shockwave therapy is non-invasive and generally well tolerated. Transient local reactions such as mild discomfort or erythema may occur, without functional limitations or recovery time.
Thoughtful configuration
The system is supplied with 13 applicators, grouped according to clinical tasks:
Different applicator shapes and diameters allow energy to be focused on localized structures (trigger points, tendon insertions) or efficiently distributed across larger areas such as major muscle groups and fascial chains.
Practical usability
Applicator selection and protocol recommendations are integrated into the system interface. This simplifies parameter setup, reduces preparation time, and minimizes the risk of operator error during treatment.
Non-invasive and clinically established
Radial shockwave therapy is applied externally, without injections or anesthesia, making it a safe and widely accepted option for the management of various musculoskeletal and myofascial pain conditions.
Therapeutic mechanism
The mechanical action of radial shockwaves stimulates tissue recovery processes, improves local circulation, reduces pain sensitivity, and supports regeneration in subacute and chronic conditions.
Minimal recovery time
No post-procedure downtime is required. In most cases, patients can immediately return to normal daily activities.
Safety controlAdjustable energy and frequency settings allow precise dosing of treatment intensity according to clinical indications and individual patient tolerance. Contraindications should be assessed and established clinical guidelines followed prior to therapy.
The system is supplied with 13 applicators, grouped according to clinical tasks:
- 6 applicators for pain-related conditions
- 3 applicators optimized for paravertebral and spinal-adjacent areas
- 4 applicators designed for fascial and myofascial therapy
Different applicator shapes and diameters allow energy to be focused on localized structures (trigger points, tendon insertions) or efficiently distributed across larger areas such as major muscle groups and fascial chains.
Practical usability
Applicator selection and protocol recommendations are integrated into the system interface. This simplifies parameter setup, reduces preparation time, and minimizes the risk of operator error during treatment.
Non-invasive and clinically established
Radial shockwave therapy is applied externally, without injections or anesthesia, making it a safe and widely accepted option for the management of various musculoskeletal and myofascial pain conditions.
Therapeutic mechanism
The mechanical action of radial shockwaves stimulates tissue recovery processes, improves local circulation, reduces pain sensitivity, and supports regeneration in subacute and chronic conditions.
Minimal recovery time
No post-procedure downtime is required. In most cases, patients can immediately return to normal daily activities.
Safety controlAdjustable energy and frequency settings allow precise dosing of treatment intensity according to clinical indications and individual patient tolerance. Contraindications should be assessed and established clinical guidelines followed prior to therapy.
Technical Specifications
- Technology: Radial acoustic shockwave therapy
- Output energy: Up to 200 mJ (equivalent to up to 7 bar)
- Operating frequency: 1-21 Hz, adjustable
- Operating modes: Manual, automatic, user-defined protocols
- Pulse delivery modes: 4 modes (continuous / burst 4 / burst 8 / burst 12)
- Applicators: 13 applicators of various shapes and diameters for different anatomical areas
- Control interface: 10-inch touchscreen display
- Power supply: 100-240 V, 50/60 Hz
- Shockwave generation principle: Electromagnetic
- Dimensions: 44 x 31 x 22 cm
- Weight: 10 kg
- Included: Wheeled flight case for transport and storage
All technical and functional parameters are identical across all versions.
»
